Physical Characteristics
Dimensions
- Corded DS2208-HC: 6.5 in. H x 2.6 in. W x 3.9 in. D (16.5 cm H x 6.6 cm W x 9.9 cm D)
- Cordless DS2278-HC: 6.9 in. H x 2.6 in. W x 3.5 in. D (17.5 cm H x 6.6 cm W x 9.0 cm D)
- Presentation Cradle: 2.8 in. H x 3.7 in. W x 4.8 in. D (7.2 cm H x 9.4 cm W x 12.2 cm D)
Weight
- Corded DS2208-HC: 5.7 oz. (161.6 g)
- Cordless DS2278-HC: 7.5 oz. (214 g)
- Presentation Cradle: 5.2 oz. (151 g)
Input Voltage Range
- DS2208-HC/DS2278-HC and Cradle: 4.5 to 5.5 VDC Host Powered; 4.5 to 5.5 VDC External Power Supply
Current
- Corded DS2208-HC Operating Current at Nominal Voltage (5.0V): 250 mA (typical). (Note: Auto-Aim and Illumination on Acquiring Image)
- Corded DS2208-HC Standby Current (idle) at Nominal Voltage (5.0V): 150 mA (typical). (Note: Auto-Aim On)
- Presentation Cradle and Micro USB Cable: 500 mA (typical) Standard USB; 1100 mA (typical) BC 1.2 USB
Color
- Healthcare White
Supported Host Interfaces
- USB, RS232, Keyboard Wedge, TGCS (IBM) 46XX over RS485
USB Certification
- USB Certification
Keyboard Support
- Supports over 90 international keyboards
User Indicators
- Direct Decode Indicator
- Good Decode LEDs
- Rear-view LEDs
- Beeper (adjustable tone and volume)
Performance Characteristics
Motion Tolerance (Handheld)
- Up to 5 in./13 cm. per second for 13 mil UPC
Swipe Speed (Hands-Free)
- Up to 30.0 in./76.2 cm. per second for 13 mil UPC
Light Source
- Aiming Pattern: Linear 624nm Amber LED
- Illumination: (2) 645nm Super-Red LEDs
Imager Field of View
- 32.8° H x 24.8° V Nominal
Image Sensor
- 640 x 480 pixels
Minimum Print Contrast
- 15% minimum reflective difference
Skew Tolerance
- +/- 65°
Pitch Tolerance
- +/- 65°
Roll Tolerance
- 0°-360°
Minimum Element Resolution
- Code 39 – 4.0 mil
- Code 128 – 4.0 mil
- Data Matrix – 6.0 mil
- QR Code – 6.7 mil
User Environment
Operating Temperature
- DS2208-HC/DS2278-HC Imagers: 32.0° to 122.0° F/0.0° to 50.0° C
- Presentation Cradle: 32.0° to 104.0° F/0.0° to 40.0° C
Storage Temperature
- -40.0° to 158.0° F/-40.0° to 70.0° C
Humidity
- 5% to 95% RH, non-condensing
Drop Specification
- Designed to withstand multiple drops at 5.0 ft./1.5 m to concrete
Tumble Specification
- Designed to withstand 250 tumbles in 1.5 ft./0.5 m tumbler
Environmental Sealing
- IP52
Approved Cleaners
- Disinfectant Ready. Refer to the product reference guide for the complete list of approved cleaners.
Electrostatic Discharge (ESD)
- DS2208/DS2278 and CR2278 Cradle: ESD per EN61000-4-2, +/-15 KV Air, +/-8 KV Direct, +/-8 KV Indirect
Ambient Light Immunity
- 0 to 10,000 Foot Candles/0 to 107,600 Lux
Radio Specifications
Bluetooth Radio
- Standard Bluetooth Version 4.0 with BLE: Class 2 33 ft. (10.0m), Serial Port and HID Profiles; output power adjustable down from 2.0 dBm in 8 Steps
Battery
Battery Capacity/Battery Type
- 2,400 mAh Li-Ion Battery
Scans per Battery Charge
- 110,000 scans at 60 Scans per Minute or 50,000 scans at 10 Scans per Minute
Operating Time per Full Charge
- 84.0 hours
Battery Charge Time (from empty)
- Standard USB:
- 14 Hour Shift: 4 hours
- Full Charge: 17 hours
- BC1.2 USB:
- 14 Hour Shift: 1 hour
- Full Charge: 5 hours
- External 5V Source:
- 14 Hour Shift: 1 hour
- Full Charge: 5 hours
- Micro USB:
- 14 Hour Shift: 1.5 hours
- Full Charge: 7 hours
- BC1.2 Micro USB:
- 14 Hour Shift: 1 hour
- Full Charge: 4 hours
Regulatory
Environmental
- RoHS EN 50581
Electrical Safety
- EN 60950-1 2ed + A11 + A1 + A12 + A2:2013, IEC 60950-1 2ed + A1 + A2, UL 60950-1, CAN/ CSA-C22.2 No. 60950-1-07
LED Safety
- IEC 62471
IT Emissions
- EN 55032 (Class B)
IT Immunity
- EN 55024
Harmonic Current Emissions
- EN 61000-3-2
Voltage Fluctuation and Flicker
- EN 61000-3-3
Radio Frequency Devices
- 47 CFR Part 15, Subpart B, Class B
Cordless Accessories
- CR2278 Presentation Cradle, Spare Battery, Micro USB Cable
Symbol Decode Capability
1D
- Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Italian Pharma)
2D
- Refer to Product Reference Guide for complete list of symbologies.
Decode Ranges (Typical)
Symbology/Resolution
- Near/Far
- Code 39: 5 mil
- 0.2 in./0.5 cm to 6.0 in./15.2 cm
- Code 128: 5 mil
- 0.6 in./1.5 cm to 4.0 in./10.1 cm
- PDF 417: 6.7 mil
- 0.8 in./2.0 cm to 5.7 in./14.5 cm
- UPC: 13 mil (100%)
- 0.5 in./1.3 cm to 14.5 in./36.8 cm
- Data Matrix: 10 mil
- 0.3 in./0.8 cm to 6.2 in./15.7 cm
- QR: 20 mil
- 0 in./0 cm to 11 in./27.9 cm
- Code 39: 5 mil
Warranty
Subject to the terms of Zebra’s hardware warranty statement, the DS2200 Series for Healthcare is warranted against defects in workmanship and materials for the following period from the date of shipment:
- DS2208-HC Corded Scanner: Sixty (60) months
- DS2278-HC Cordless Scanner: Thirty-six (36) months
- CR2278 Presentation Cradle: Thirty-six (36) months
- Battery: Twelve (12) months For the complete Zebra hardware product warranty statement, please go to: Zebra Warranty
Recommended Services
- Zebra OneCare® Select
- Zebra OneCare Essential
