Technical Specifications
| Mechanical | |
| Dimensions | 99.6 x 163.7 x 31.7 mm (4 x 6.4 x 1.3″) |
| Weight | 295 g (10.4 oz) |
| Enclosure material | Plastic |
| Hardware | |
| Management interface | Ethernet In-Band |
| Networking interface | (8) GbE RJ45 ports |
| PoE interface | (4) PoE/PoE+ (Pins 1, 2+; 3, 6-) |
| Total non-blocking throughput | 8 Gbps |
| Switching capacity | 16 Gbps |
| Power method | 54V DC, 1.1A power adapter |
| Power supply | 54V, external, 60W |
| Supported voltage range | 50—57V DC |
| Max. power consumption | 8W (Excluding PoE output) |
| Total available PoE | 52W*
*With an external 60W power adapter. |
| Max. PoE wattage per port by PSE | PoE+: 30W |
| Button | Factory reset |
| Operating temperature | -15 to 40° C (5 to 104° F) |
| Operating humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
| LEDs | |
| System | Status |
| Ethernet | PoE
Speed/link/activity |
| PoE | Link/activity |
| Application Requirements | |
| UniFi Network | Version 7.2.94 and later |
