Standard Features
- 300 dpi (11.8 dots/mm) print resolution
- 2 GB flash memory
- Image size: 1006 x 640 pixels
- Auto calibration of ribbon
- USB 2.0 and Ethernet 10/100 connectivity
- 100 card capacity auto-adjusting input hopper (30 mil)
- 100 card capacity output hopper (30 mil)
- Manual card feeding capability with LED bezel
- Graphical color LCD
- 3 Tricolor printer status indicator lights
- Kensington® secure lock slot
- Print Touch NFC tag for online printer help and documentation access
- Printer host authentication
- Data encryption
- Three-year limited warranty on printer and printhead
Printing Specifications
- Dye-sublimation thermal transfer direct to card print method
- Full-color or monochrome printing
- Single and dual-sided printing
- Edge-to-edge printing on standard CR-80 media
- Printing throughput (cards per hour):
- 900 cards/hour single-sided monochrome
- 200 cards/hour single-sided YMCKO
- 140 cards/hour dual-sided YMCKOK
- 450 cards/hour dual-sided monochrome
Media Specifications
- Supplies Specifications:
- Ribbons are included in a simple-to-load recyclable cartridge.
- Ribbon Description and Cartridge Image Count:
- YMCKO*: 200
- YMCKO*: 300
- YMCKOK*: 200
- ½ YMCKO*: 400
- ½ YMCKOKO*: 250
- KrO*: 700
- KdO*: 700
- Black Monochrome*: 2000
- Black Monochrome: 1500
- White Monochrome*: 1500
- Red Monochrome: 1500
- Blue Monochrome: 1500
- Gold Monochrome: 1500
- Silver Monochrome: 1500
- Cleaning roller is included with each ribbon.
- Two available cleaning kit options: your choice of two (2) or five (5) isopropyl alcohol cleaning cards (1,000 images/card).
- Card Compatibility:
- Card Thickness: 10-40 mil*
- Card Size: CR80 ISO 7810 ID-1 format, CR79*
- Card Material: PVC and PVC composite
- Adhesive back and writable back cards
- *Note: Spot color or monochrome printing recommended only on >20 mil thick cards and CR79 cards.
Operating Characteristics
- Operating Temp: 59º F to 95º F / 15º C to 35º C
- Storage Temp: 23º F to 158º F / -5º C to 70º C
- Operating Humidity: 20% to 80% non-condensing
- Media Storage:
- Temperature: 41º F to 77º F / 5º C to 25º C
- Humidity: 35% to 65% non-condensing
- Electrical:
- Auto-switching single-phase AC power
- Operating range: 90-132VAC and 190-264VAC RMS
- Frequency range: 47-63 Hz
- FCC Class A
Physical Characteristics
- Dimensions (Single Sided):
- 10.2 in. H x 6.2 in. W x 15.1 in. D
- 258 mm H x 157 mm W x 383 mm D
- Dimensions (Dual Sided):
- 10.2 in. H x 6.2 in. W x 18.4 in. D
- 258 mm H x 157 mm W x 468 mm D
- Weight:
- Single Sided: 8.8 lbs (4.0 kg)
- Dual Sided: 9.7 lbs (4.4 kg)
Communications and Interface Capabilities
- USB 2.0 (Standard)
- Built-in 10/100 Ethernet (Standard)
- 802.11ac (Optional)
Encoding Options and Specifications
- Magnetic stripe encoder — ISO 7811 (new and pre-encoded; tracks 1, 2, and 3; high and low coercivity; stripe down and stripe up with dual-sided printers)
Printer Drivers
- Microsoft Windows Certified:
- Windows Server 2008 (32 and 64 bit)
- Windows 7 (32 bit and 64 bit)
- Windows 8 and Windows 8.1 (32 bit and 64 bit compatible)
- Windows Server 2012 (64 bit)
- Windows 10 (32 bit and 64 bit)
- Windows Server 2016
- Windows drivers include:
- Color-coded printer status indicators for the operator
- Black panel extraction and controls for specialty ribbon panels with image preview
- Configuration utility to limit access by operators to change image quality and printer settings
- Advanced printer configuration, security settings, and diagnostics capabilities
- Linux: Ubuntu 16.X (64 Bit)
- Apple: MAC OS X 10.13.X (64 bit)
- For an up-to-date listing of supported systems, please visit www.zebra.com.
