Decoding Capability:
- 1D / Linear Codes: Auto discriminates all standard 1D codes including GS1 DataBarâ„¢ linear codes.
- 2D Codes: Aztec Code; China Han Xin Code; Data Matrix; MaxiCode; Micro QR Code; QR Code; Dot code.
- Postal Codes: Australian Post; China Post; IMB; Japanese Post; KIX Post; Planet Code; Portuguese Post; Postnet; Royal Mail Code (RM4SCC); Swedish Post.
- Digital Watermarking: Digimarc Barcodes (PD9630-HP and PD9630-DC)
Electrical:
- Current Operating (Typical):
- PD9630-SR: 200mA @ 5V; 120mA @ 12V
- PD9630-HP/ PD9630-DC: 280mA @ 5V / 140mA @ 12V
- Standby/Idle (Typical): 187mA @ 5V / 92mA @ 12V
- Input Voltage: 5 – 30 VDC ± 5%
Environmental:
- Ambient Light: 0 – 100,000 lux
- Drop Resistance: Withstands 50 drops from 2.5 m / 8.2 ft @ 20 °C / 68 °F; Withstands 50 drops from 2.0 m / 6.6 ft @ -20 °C / -4 °F
- Tumble: 5,000 @ 1 m / 3.3 ft
- Trigger Resistance: Withstands 10 million hits
- ESD Protection (Air Discharge): 20 kV
- Humidity (Non-Condensing): 0 – 95%
- Particulate and Water Sealing: IP67 and IP65
- Temperature:
- Operating: -20 to 50 °C / -4 to 122 °F
- Storage/Transport: -40 to 70 °C / -40 to 158 °F
Interfaces:
- Interfaces: RS-232 / USB
Physical Characteristics:
- Colors Available: Yellow/Black
- Dimensions H x L x W: 19.0 x 14.0 x 7.9 cm / 7.5 x 5.5 x 3.1 in
- Weight: 318.0 g / 11.2 oz
Reading Performance:
- Imager Sensor:
- PD9630-SR/HP: 1280 x 800
- PD9630-DC: 1280 x 800 color sensor
- Light Source:
- Aiming: 630 – 680 nm VLD
- Illumination: White LED reading light
- Print Contrast Ratio (Minimum): 15%
- Reading Angle:
- Pitch: +/- 52°
- Roll (Tilt): 360°
- Skew (Yaw): +/- 52°
- Field Of View:
- SR and HP: 38° H, 24° V
- DC: 50° H, 33° V
- Reading Indicators: Beeper (Adjustable Tone and Volume); Datalogic’s 3GL™ (Three Green Lights) technology for good-read feedback; Datalogic ‘Green Spot’ on the Code; Dual Good Read LEDs; Vibration.
- Resolution (Maximum):
- PD9630-SR/PD9630-DC: 1D Codes: 3 mil; 2D Codes: 6 mil
- PD9630-HP: 1D Codes: 2.5 mil; 2D Codes: 4 mil
Decoding Capability (Typical Depth of Field):
- PD9630-SR / PD9630-HP:
- Code 128: 5 mils: 6.4 to 30.9 cm / 2.5 to 12.2 in, 20 mils: 4 to 103.7 cm / 1.6 to 40.8 in, 40 mils: 5.5 to 175 cm / 2.2 to 68.9 in
- EAN/UPC: 13 mils: 4 to 67.5 cm / 1.5 to 26.5 in
- DataMatrix: 10 mils: 6 to 30 cm / 2.5 to 11.8 in
- PD9630-DC:
- Code 128: 2.5 mils: 6.3 to 11.5 cm / 2.5 to 4.5 in, 5 mils: 3.8 to 41 cm / 1.5 to 16.1 in, 20 mils: 4 to 157 cm / 1.6 to 61.8 in
- EAN/UPC: 13 mils: 4 to 120 cm / 1.5 to 40.2 in
- PDF417: 10 mils: 0.5 to 46.1 cm / 0.2 to 18.1 in
- DataMatrix: 4 mils: 6.5 to 9.3 cm / 2.5 to 3.6 in, 10 mils: 4.2 to 32 cm / 1.6 to 12.6 in, DataMatrix 10 mils: 4.2 to 30.2 cm / 1.6 to 11.8 in
Safety & Regulatory:
- Agency Approvals: The product meets necessary safety and regulatory approvals for its intended use. The Regulatory Addendum for this product can be referred to for a complete list of certifications.
- Environmental Compliance: Complies to China RoHS; Complies to EU RoHS; Complies to R.E.A.C.H.
- Laser Classification: Caution Laser Radiation – Do not stare into beam CDRH Class II; IEC 60825 Class 2
- LED Classification: IEC 62471 LED Class: Exempt
Utilities:
- Datalogic Aladdinâ„¢: Datalogic Aladdin configuration program is available for download at no charge.
- OPOS / JavaPOS: OPOS and JavaPOS Utilities are available for download at no charge.
- Remote Host Download: Available on request
Warranty:
- Warranty: 3-Year Factory Warranty
