Ubiquiti UniFi AC Mesh + 3 YRS Warranty

Features:

Mesh-Compatible WiFi5 Access Point with Customizable Antennas + 3YR Warranty

SKU: UAP-AC-M
Related Products:

No ratings on this product.

$202.82

Categories: Network Products
Tag: Network Products, Ubiquiti, UniFi WiFi
Ubiquiti UniFi AC Mesh: Versatile and Powerful Wireless Solution
Enhance your network with the Ubiquiti UniFi AC Mesh, a robust and versatile access point designed for both indoor and outdoor use. This compact device offers an expansive coverage of 140 m² (1,500 ft²) and supports over 250 connected devices, making it ideal for medium to large-sized areas. Powered by WiFi5 with 2x2 MIMO technology, it ensures reliable and fast wireless performance. The UniFi AC Mesh stands out with its detachable antenna and compatibility with the optional UMA-D antenna, offering flexibility and enhanced range coverage. Additionally, the device features a weather-resistant enclosure, making it perfect for outdoor deployment in various environmental conditions. Powered using PoE, with a power adapter included for single unit purchases, installation and power management are straightforward. The UniFi AC Mesh can be easily mounted on a wall, pole, or Ubiquiti high-gain antenna, providing various deployment options to suit your specific needs. The device is managed through the feature-rich UniFi Controller, allowing for detailed analytics, RF mapping for optimal placement, and advanced RF performance features. With its capability for wireless uplink and support for guest portal/hotspot functionality, the UniFi AC Mesh is a comprehensive solution for extending your wireless network reach efficiently and affordably.

Extend your peace of mind with an additional three-year warranty on top of the standard coverage; learn more about this extended warranty option.

Technical Specifications

Mechanical
Dimensions 353 x 46 x 34.4 mm (13.9 x 1.8 x 1.4″)
Weight 152 g (5.4 oz)
Hardware
Networking interface (1) GbE port
Management interface Ethernet

Bluetooth
Power method 24V passive PoE (Pairs 4, 5+; 7, 8 return)

PoE alternative A (Pairs 1, 2+; 3, 6 return)
Power supply Gigabit PoE adapter 24V, 0.5A*

*5-packs do not come with PoE adapters.
Supported voltage range 44—57V DC
Max. power consumption 8.5W
Max. TX power

2.4 GHz

5 GHz

 20 dBm20 dBm
MIMO

2.4 GHz

5 GHz

 2 x 22 x 2
Throughput rate

2.4 GHz

5 GHz

 300 Mbps867 Mbps
Antenna gain

2.4 GHz

5 GHz

 3 dBi4 dBi
Button Factory reset
Mounting Wall/pole/fast-mount (Included)
Operating temperature -30 to 70° C (-22 to 158° F)
Operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC, UKCA
Software
WiFi standards 802.11a/b/g/n/ac
Wireless security WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
VLAN 802.1Q
BSSID Up to 4 per radio
Advanced QoS Per-user rate limiting
Guest traffic isolation Supported
Power save Supported
WMM Voice, video, best effort, and background
Concurrent clients 250+
Supported Data Rates (Mbps)
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40)
802.11ac 6.5 Mbps to 867 Mbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80)
