Physical Characteristics
| Specification | Corded | Cordless |
|---|---|---|
| Dimensions (in.) | 7.3 H x 3.0 W x 5.2 D | 7.3 H x 3.0 W x 5.6 D |
| Dimensions (cm) | 18.5 H x 7.7 W x 13.2 D | 18.5 H x 7.7 W x 14.3 D |
| Weight | 10.72 oz./304 g | 14.18 oz./402 g |
| Operating Current | 360 mA (RMS typical) | N/A |
| Standby Current | 100 mA (RMS typical) | N/A |
| Color | Industrial Green | Industrial Green |
| Input Voltage Range | Host powered: 4.5-5.5 VDC, External power supply: 11.4-12.6 VDC | N/A |
Performance Characteristics
| Specification | Details |
|---|---|
| Scans per Full Charge | 100,000+ |
| Image Capture | Basic |
| Illumination | Direct: Two warm white light LED; Diffuse: Ring of red 634 nm LEDs |
| Aimer | 655 nm laser |
| Imager Field of View | Horizontal: 31°, Vertical: 23° |
| Image Sensor | 1,280 x 960 pixels |
| Minimum Print Contrast | 15% minimum reflective difference |
| Skew/Pitch/Roll | Skew: ± 60°, Pitch: ± 60°, Roll: ± 360° |
Decode Capabilities
| Type | Supported Formats |
|---|---|
| 1D | Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Italian Pharma) |
| 2D | PDF417, Micro PDF417, Composite Codes, TLC-39, Aztec, DataMatrix, MaxiCode, QR Code, Micro QR, Chinese Sensible (Han Xin), Postal Codes |
User Environment
| Specification | Corded | Cordless |
|---|---|---|
| Operating Temp. (°F) | -22 to 122 | -4 to 122 |
| Operating Temp. (°C) | -30 to 50 | -20 to 50 |
| Storage Temp. (°F) | -40 to 158 | -40 to 158 |
| Storage Temp. (°C) | -40 to 70 | -40 to 70 |
| Humidity | 5% to 95% non-condensing | 5% to 95% non-condensing |
Utilities and Maintenance
| Service | Description |
|---|---|
| 123Scan | Programs scanner parameters, upgrades firmware, provides scanned barcode data and prints reports. |
| Scanner SDK | Generates a fully-featured scanner application, including documentation, drivers, test utilities and sample source code. |
| Scanner Management Service (SMS) | Remotely manages your Zebra scanner and queries its asset information. |
| Network Connect | Seamlessly connects 3600 Series scanners directly to your Industrial Ethernet network with no additional conversion equipment. |
Wireless Connectivity
| Specification | Bluetooth Details |
|---|---|
| Bluetooth Radio | Bluetooth Class 1, Version 4.0 (LE), serial port (SPP)and HID profiles |
| Data Rate | 3 Mbit/s (2.1 Mbit/s) for Classic Bluetooth; 1 Mbit/s (0.27 Mbit/s) for Low Energy |
| Radio Range | Direct line of sight in open air: Class 1: Minimum 300 ft. (100.0 m); Class 2: Minimum 30 ft. (10.0 m) |
Regulatory
| Type | Compliance |
|---|---|
| Environmental | RoHS EN 50581: 2012 |
| Electrical Safety | EU Safety: EN 60950-1: 2006 + A11: 2009 + A1: 2010 + A12: 2011 + AC 2011 + A2: 2013; International Safety: IEC 60950-1: 2005 + A1: 2009 + A2: 2013; US/Canada Safety: UL 60950-1, second edition, CAN/CSA-C22.2 No. 60950-1-07 |
| Laser/LED Safety | Exempt Risk Group LED per IEC/EN 62471 (Ed 1); Class 2 Laser per IEC/EN 60825-1 (Ed 3); Complies with 21CFR1040.10 |
| EMI/RFI | IT Emissions: EN 55022: 2010/AC: 2011 (Class B); IT Immunity: EN 55024: 2010; Heavy Industrial: EN 61000-6-2: 2005/AC:2005; Harmonic Current Emissions: EN 61000-3-2: 2006 + A1: 2009 + A2: 2009 (Class B); Voltage Fluctuation and Flicker: EN 61000-3-3: 2013; Medical Electrical Equipment: EN 60601-1-2: 2007/AC: 2010, IEC 60601-1-2: 2007 (Modified); Radio Frequency Devices: 47 CFR Part 15, Subpart B, Class B Digital Apparatus: ICES-003 Issue 5, Class B |
Decode Range (Typical)
| Symbology/Resolution | Near/Far |
|---|---|
| Code 39: 3.0 mil | 0.2-2.8 in./0.5-7.1 cm |
| Code 39: 5.0 mil | 0.2-2.8 in./0.5-7.1 cm |
| PDF417: 6.6 mil | 40.2-3.2 in./40.5 |
Warranty
| Subject to the terms of Zebra’s hardware warranty statement, the DS3608-DP / DS3678-DP is warranted against defects in workmanship and materials for a period of: Scanner and Cradle: thirty-six (36) months, Battery: twelve (12) months from the date of shipment. For complete warranty statement, go to: |
