Specifications |
|---|---|
Physical Characteristics |
|
| Dimensions | Corded: 7.3 in. H x 3.0 in. W x 5.2 in. D<br> Cordless: 7.3 in. H x 3.0 in. W x 5.6 in. D |
| 18.5 cm H x 7.6 cm W x 13.2 cm D<br> 18.5 cm H x 7.7 cm W x 14.2 cm D | |
| Weight | Corded: 10.1 oz./287 g<br> Cordless: 13.6 oz./386.5 g |
| Input Voltage Range | Host powered: 4.5 VDC min., 5.5 VDC max.<br> External power supply: 11.4 VDC min., 12.6 VDC max. |
| Operating Current | LI3608 (corded): 170 mA (RMS typical) |
| Standby Current | LI3608 (corded): 40 mA (RMS typical) |
| Color | Industrial Green |
| Supported Host Interfaces | USB, RS232, Keyboard Wedge<br> Industrial Ethernet: EtherNet/IP, Profinet, Modbus TCP & Std TCP/IP |
| Battery | PowerPrecision+ 3100 mAh Li-Ion rechargeable battery |
| User Indicators | Direct decode indicator; LEDs; beeper; vibration |
| Performance Characteristics | |
| Scans per Full Charge | 140,000+ |
| Illumination | Two (2) 617nm Amber LEDs |
| Aimer | 655 nm laser |
| Imager Field of View | 35° |
| Image Sensor | 1,500 pixels |
| Minimum Print Contrast | 15% minimum reflective difference |
| Types Skew/Pitch/Roll | Skew: ± 65°<br> Pitch: ± 65°<br> Roll: ± 45° |
| Decode Capabilities² | |
| 1D | Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Italian Pharma) |
User Environment |
|
| Operating Temp. | Corded: -22° F to 122° F/-30° C to 50° C<br> Cordless: -4° F to 122° F/-20° C to 50° C |
| Storage Temp. | -40° F to 158° F/-40° C to 70° C |
| Humidity | 5% to 95% non-condensing |
| Drop Specification | LI36X8: Withstands multiple 10.0 ft/3.0 m drops to concrete at room temperature |
| LI3678: Withstands multiple 8.0 ft/2.4 m drops to concrete at -20° C to 50° C | |
| LI3608: Withstands multiple 8.0 ft/2.4 m drops to concrete at -30° C to 50° C | |
| Tumble Specification | 7500 3.3 ft./1.0 m tumbles |
| Sealing | Scanner: IP65 and IP68 per applicable IEC sealing specifications |
| FLB cradle: IP65 | |
| ESD | Per EN61000-4-2, ±25 KV air discharge, ±10 KV direct discharge, ±10 KV indirect discharge |
| Ambient Light Immunity | 0 to 10,037 Foot Candles/0 to 108,000 Lux (direct sunlight) |
| Wireless Connectivity | |
| Bluetooth Radio | Bluetooth Class 1, Version 4.0 (LE), serial port (SPP) and HID profiles |
| Data Rate | 3 Mbit/s (2.1 Mbit/s) for Classic Bluetooth |
| 1 Mbit/s (0.27 Mbit/s) for Low Energy | |
| Radio Range | Direct line of sight in open air: Class 1: Minimum 300 ft. (100.0 m); Class 2: Minimum 30 ft. (10.0 m) |
Regulatory |
|
| Environmental | RoHS EN 50581: 2012 |
| Electrical Safety | EU Safety: EN 60950-1: 2006 + A11: 2009 + A1: 2010 + A12: 2011 + AC 2011 + A2: 2013; |
| International Safety: IEC 60950-1: 2005 + A1: 2009 + A2: 2013; | |
| US/Canada Safety: UL 60950-1, second edition, CAN/CSA-C22.2 No. 60950-1-07 | |
| LED Safety | International LED Safety: IEC 62471: 2006 (Ed.1.0); |
| EN 62471: 2008 (LED) | |
| EMI/RFI | IT Emissions: EN 55022: 2010/AC: 2011 (Class B); |
| IT Immunity: EN 55024: 2010; Heavy Industrial: EN 61000-6-2: 2005/AC:2005; | |
| Harmonic Current Emissions: EN 61000-3-2: 2006 + A1: 2009 + A2: 2009 (Class B); | |
| Voltage Fluctuation and Flicker: EN 61000-3-3: 2013; | |
| Medical Electrical Equipment: EN 60601-1-2: 2007/AC: 2010, IEC 60601-1-2: 2007 (Modified); | |
| Radio Frequency Devices: 47 CFR Part 15, Subpart B, Class B; | |
| Digital Apparatus: ICES-003 Issue 5, Class B | |
Decode Ranges (Typical) |
|
| Symbology/Resolution | Near/Far |
| Code 39: 4 mil | 4.0-10.0 in./10.2-25.4 cm |
| Code 39: 7.5 mil | 1.5-19.0 in./3.8-48.3 cm |
| UPC: 13 mil (100%) | 1.0-31.0 in./2.5-78.7 cm |
| Code 39: 20 mil | 1.0-42.0 in./0-106.7 cm |
For more detailed specifications, please visit the official product specification page.
To learn more about Data Capture DNA and its applications, visit www.zebra.com/datacapturedna.
To see a complete warranty statement,click here for the Zebra’s warranty page.
