Specification |
Description |
|---|---|
Physical Characteristics |
|
| Dimensions | Corded: 7.3 in. H x 3.0 in. W x 5.2 in. D<br> Cordless: 7.3 in. H x 3.0 in. W x 5.6 in. D |
| Weight | Corded: 10.76 oz./305 g
Cordless: 14.34 oz./407 g |
| Input Voltage Range | Host powered: 4.5 VDC min., 5.5 VDC max.
External power supply: 11.4 VDC min., 12.6 VDC max. |
| Operating Current | DS3608-SR (corded): 360 mA (RMS typical) |
| Standby Current | DS3608-SR (corded): 100 mA (RMS typical) |
| Color | Industrial Green |
| Supported Host Interfaces | USB, RS232, Keyboard Wedge
Industrial Ethernet: EtherNet/IP, Profinet, Modbus TCP & Std TCP/IP |
| Battery | PowerPrecision+ 3100 mAh Li-Ion rechargeable battery |
| User Indicators | Direct decode indicator; LEDs; beeper; vibration |
Performance Characteristics |
|
| Scans per Full Charge | 100,000+ |
| Image Capture | Basic |
| Illumination | One (1) 660 nm LED |
| Aimer | 610 nm LED |
| Imager Field of View | Horizontal: 42°, Vertical: 28° |
| Image Sensor | 1,280 x 800 pixels |
| Minimum Print Contrast | 15% minimum reflective difference |
| Skew/Pitch/Roll | Skew: ± 60°, Pitch: ± 60°, Roll: ± 360° |
Decode Capabilities |
|
| 1D | Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Italian Pharma) |
| 2D | PDF417, Micro PDF417, Composite Codes, TLC-39, Aztec, DataMatrix, MaxiCode, QR Code, Micro QR, Chinese Sensible (Han Xin), Postal Codes |
| Digimarc | Digital watermark technology |
| IUID Support | Supports IUID parsing, the ability to read and Separate IUID fields per application requirements |
| User Environment | |
| Operating Temp. | Corded: -22° F to 122° F/-30° C to 50° C
Cordless: -4° F to 122° F/-20° C to 50° C |
| Storage Temp. | -40° F to 158° F/-40° C to 70° C |
| Humidity | 5% to 95% non-condensing |
| Drop Specification | DS36X8: Withstands multiple 10.0 ft/3.0 m drops to concrete at room temperature |
| DS3678: Withstands multiple 8.0 ft/2.4 m drops to concrete at -20° C to 50° C | |
| DS3608: Withstands multiple 8.0 ft/2.4 m drops to concrete at -30° C to 50° C | |
| Tumble Specification | 7500 3.3 ft./1.0 m tumbles |
| Sealing | Scanner: IP65 and IP68 per applicable IEC sealing specifications |
| FLB cradle: IP65 | |
| ESD | Per EN61000-4-2, ±25 KV air discharge, ±10 KV direct discharge, ±10 KV indirect discharge |
Wireless Connectivity |
|
| Bluetooth Radio | Bluetooth Class 1, Version 4.0 (LE), serial port and HID profiles |
| Data Rate | 3 Mbit/s (2.1 Mbit/s) for Classic Bluetooth
1 Mbit/s (0.27 Mbit/s) for Low Energy |
| Radio Range | Direct line of sight in open air: Class 1: Minimum 300 ft. (100.0 m); Class 2: Minimum 30 ft. (10.0 m) |
| Decode Ranges (Typical) | |
| Symbology/Resolution | Near/Far |
| Code 128: 5 mil | 1.3-6.7 in./3.3-17 cm |
| Code 128: 20 mil | 2.8-28.0 in./7.1-71.1 cm |
| Code 128: 40 mil | 1.7-60 in./4.4-152.4 cm |
| Datamatrix: 7.5 mil | 1.9-6.0 in./4.8-15.2 cm |
| Datamatrix: 10.0 mil | 1.4-8.6 in./3.5-21.8 cm |
Regulatory |
|
| Environmental | RoHS EN 50581: 2012 |
| Electrical Safety | EU Safety: EN 60950-1: 2006 + A11: 2009 + A1: 2010 + A12: 2011 + AC 2011 + A2: 2013 |
| International Safety: IEC 60950-1: 2005 + A1: 2009 + A2: 2013 | |
| US/Canada Safety: UL 60950-1, second edition, CAN/CSA-C22.2 No. 60950-1-07 | |
| LED Safety | International LED Safety: IEC 62471: 2006 (Ed.1.0); EN 62471: 2008 (LED) |
| EMI/RFI | IT Emissions: EN 55022: 2010/AC: 2011 (Class B) |
| IT Immunity: EN 55024: 2010 | |
| Heavy Industrial: EN 61000-6-2: 2005/AC:2005 | |
| Harmonic Current Emissions: EN 61000-3-2: 2006 + A1: 2009 + A2: 2009 (Class B) | |
| Voltage Fluctuation and Flicker: EN 61000-3-3: 2013 | |
| Medical Electrical Equipment: EN 60601-1-2: 2007/AC: 2010, IEC 60601-1-2: 2007 (Modified) | |
| Radio Frequency Devices: 47 CFR Part 15, Subpart B, Class B | |
| Digital Apparatus: ICES-003 Issue 5, Class B | |
For more detailed specifications, please visit the official product specification page.
To learn more about Data Capture DNA and its applications, visit www.zebra.com/datacapturedna.
To see a complete warranty statement,click here for the Zebra’s warranty page.
